Dropside614

Model:	Weichai HK614 Dropside 14ft
Body Dimension( L x W x H ):	4,180 x 2,100 x 2,100mm
Cab and Chassis Dimension( L x W x H ):	5,995 x 1,995 x 2,400mm
Engine Model:	WP3NQ150E50
Engine Type:	In-line 4 Cylinder Turbocharging, intercooling High-Pressure Common Rail 16 Valves
HP:	150
Emission Standard:	Euro 5
Displacement:	2.97L
Max Power Output:	110Kw/3000rpm
Max. Torque (N.m):	430 N.m (1400-2400)
Fuel Type:	DIESEL
Transmission:	Weichai Fast C6J45TB
Clutch Type:	Dry Type, Diaphragm Spring
Clutch Plate Diameter:	⌀ 300
Front Leaf Spring:	Vertical Steel Plate Spring (X3) Two Way Cylindrical Shock Absorber
Rear Leaf Spring:	Vertical Steel Plate Spring (5 + 3) Two Way Cylindrical Shock Absorber
Brake System:	Double Circuit Pneumatic Break with Front Drum and Rear Drum with ABS
Parking Brake:	Spring Energy Storage Air Break
Steering System:	Hydraulic Power Steering
Tire size:	7.50R16LT / 14PR (rear dual tires)
Tire Quantity:	6 + 1
Wheel Base (mm):	3300mm
GVW (kg):	8000kg
Max Loading (kg):	6000kg
Curb Weight (kg):	2000kg
Seating Capacity:	3
Fuel Tank Capacity:	120L aluminum Alloy Fuel tank
In-Vehicle Entertainment	AM/FM(MP3)
Electrical System Rated Voltage	24V
Cabin	Top Storage Box
	With Air Conditioner
	Power Window
	Central Lock
	USB Power Port
	Remote Keyless Entry
	Electric Horn
	Air Horn
Maintenance Free battery	•
Battery Main Switch	•
USB Power Port	•
Spare Tire	•
Fog Lamps	•
Daytime Running Light	•
Reserved PTO left	•
