WEICHAI HK27 MODERN PUV (CLASS 3) EURO V

SPECIFICATION

ENGINE Model Weichai WP2.5NQ150E50
Emission Standard Euro V
Engine Type High Pressure Common Rail
Rated power (Kw) 114
Max Torque (N.m) 400
HP 155
Displacement 2.5
GEAR BOX Brand and Model Weichai Fast C5J40T-B
REAR AXLE Loading (Kg) 5000kg
Ratio 4.33
BRAKE SYSTEM Auxiliary braking Air brake
Brake type Drum
WEIGHT Curb weight (kg) 3700
Chassis weight (kg) 1800
Bus body weight (kg) 1900
loading (kg) 3055
Luggage (kg) 100
GVW (kg) 6755
Tires 215/75R17.5
Suspension 3/5+2
Chassis frame height 193mm
FUEL TANK 120L Aluminum alloy Fuel tank
VEHICLE PARAMETERS Long (mm) 6995
Width 2100(inner)/2280(outer)
Height(mm) 2850
Wheel base (mm) 3800
Passengers 26+1
MAIN BODY CONFIGURATION Body Structure Rectangular hollow section welded
Interior decoration Molding interior trim
Door to door pump Pneumatic foldong door
Windshield, side window Sliding windows, tail sealing window
Air conditioning / ventilation window Air conditioning / JY-KT14W
Rearview system Shaped rear-view mirror, inside mirror
Audiovisual system MP3
Wiper Routine
Seats Adjustable passenger seat,
Adjustable driver seat
Paint Plain paint (color optional)
Floor leather Standard floor cover
Camera Built in closed loop multi-channel camera
TV Folding TV
Luggage compartment/Rack Two luggage compartments, overhead
luggage rack and under flooring luggage
